Specifications
Applicable Material: Titanium alloys, aluminum alloys, superalloys, cobalt-chromium alloys, stainless steel, mold steel, etc.
Function: powder suction, sieving, feeding, slag discharge
Atmosphere protection: Yes
Ultrasound: Yes
dB(A) Noise: 75±5
Filter cleaning method: Pulse blowback
Suction caliber (mm): Sanitary quick connector
Return air caliber(mm): Sanitary quick connector
Cartridge service life (h): 2000h
Filtration efficiency: 99% (for 3—5μm)
Screen mesh number: ≦300 mesh
Power supply (V/Hz): 380V/50HZ
Power: 5 KW
Size: 1300 x 1200 x 2700mm
Weight: about 700kg
Oxygen content requirements: Oxygen content during cycle operation≤5000ppm (depends on the material）
Wash time: ≤30min
Powder supply capacity: for one printer
Powder feeding speed: ≥1.5L/min（Aluminum alloy） ≥2.0L/min (Stainless steel)
Powder: ≥0.8L/min
Conveyor pipeline: Anti-static steel wire hose
Pipe diameter: Ø51mm
Delivery principle: Positive + Negative pressure
New powder tank volume: 55L
Old powder tank volume: 70L
Operation method: Automatic + Manual
