MultiJet

MultiJet technology produces 3D prints by rapidly spraying and curing liquid photopolymer in a layer by layer fashion. Plastics are 3D printed like printing with a Inkjet printing head which places small particles of light curing plastic on a print bed. This layer is then hardened with UV light, the build plate retracts by one step and a new layer is applied. The layer thickness can be extremely thin, like the resin technology.



In addition to being really fast technology, MultiJet comes with several other advantages. Because it is a more controlled process, it can print fast various materials, with high level of detail and precision. And unlike both FFF and resin technology, there’s no need to mechanically remove the support structure, as the support material is wax, which can be easily removed, allowing geometries with no access to be printed.



The plastic 3D printed models made with MultiJet systems have a high surface quality. The materials available are rigid, elastomeric, flexible, transparent, high temperature. Also, there is a version for 100% wax for model casting, ideal for jewelry.

Display per page
Accessing high fidelity, functional plastic or elastomeric prototypes has never been faster or easier, with up to 3x higher 3D printing speeds than similar class printers and finished part delivery up to 4x faster with 3D Systems MJP EasyClean System.
3D Printing TechnologyMultiJet (MJP)
Build Volume295 x 211 x 142 mm
Layer Height32 microns
Product Weight211 kg
The ProJet™ MJP 2500W Plus 3D printer is the specialized model of the ProJet 3D Systems series that meets the needs of the jewelry industry. Offered at a particularly affordable price for this product category.
3D Printing TechnologyMultiJet (MJP)
Build Volume294 x 211 x 144 mm
Layer Height16 microns
Product Weight211 kg
The ProJet MJP 5600 is a large-format, Multi-material 3D printer that offers print speeds up to two times faster than similar PolyJet machines. Plus, with a larger build volume, you can leverage the ProJet MJP 5600’s capabilities to reduce part costs by up to 40% compared to those of competing multi-material 3D printers.
3D Printing TechnologyMultiJet (MJP)
Build Volume518 x 381 x 300 mm
Layer Height13 microns & 16 microns
Material Compatibility5 base materials: rigid white, black or clear, elastomeric black or natural
The MJP 300W 3D Printer offers detailed wax pattern printing for jewelry, compatible with standard lost-wax casting processes. It emphasizes accuracy in design replication and operational efficiency for modern jewelry manufacturing.
3D Printing TechnologyMultiJet (MJP)
Build Volume294 x 211 x 144 mm (11.6 x 8.3 x 5.6 in)
Layer Thickness8μm - 25μm
3D Printing TechnologyMultiJet (MJP)
