Laser Type
|
Diode-pumped solid-state laser Nd:YVO₄
|
|
Laser Wavelength
|
354.7nm
|
|
Laser Power
|
1000/2000/3000mW
|
|
Process
|
Intelligent positioning - Vacuum press recoat
|
|
Normal Build
|
0.1mm
|
|
Quick Build
|
0.1~0.15mm
|
|
Precision Build
|
0.05~0.1mm
|
|
Beam (diameter@1/e2)
|
0.10~0.16mm (Normal) 0.10~0.50mm (Super)
|
|
Scanning Galvanometer
|
High Speed Scanning Galvanometer
|
|
Parts Scanning Speed
|
6.0m/s (recommended)
|
|
Blank Jumping Speed
|
10.0m/s (recommended)
|
|
Reference Building Speed
|
90~220g/h (Super)
|
|
Elevator Position Repeatability
|
±0.01mm
|
|
Elevator Motor
|
High Accuracy Servo Motor
|
|
Benchmark Platform
|
marble benchmark platform
|
|
Resin Vat Volume
|
Approx. 450L@400mm(Z)
|
|
XY Platform
|
800mm(X)×800mm(Y)
|
|
Z Axis
|
550mm
|
|
Max Weight
|
100kg@400mm(Z)
|
|
Resin Heated Style
|
Hot air
|
|
Photopolymer Resin
|
ZR680 (Accurate & White) ZR710 (Tough & White) ZR820 (High Transparency)
|
|
Network
|
Ethernet, TCP/IP, IEEE802.3
|
|
Control Software
|
iSLA (ZERO 5.0)
|
|
Data Preparation Software
|
3dLayer
|
|
Data Interface
|
CLI file, SLC file, STL file
|
|
Power
|
200~240VAC 50/60Hz, single phase, 5 / 10Amps
|
|
Ambient Temperature
|
20-26ºC
|
|
Relative Humidity
|
Less than 40%, non-condensing
|
|
Installation Condition Size
|
1.50m(W)×1.40m(D)×2.20m(H) (Operating computer is not included)
|
|
Installation Condition Weight
|
Approx. 1000kg
|
|
Warranty
|
Laser: 5000 hours or 12 months (whichever comes first) Main Machine: 12 months from installation date
|
