Specifications
General Specifications
Max Machining Speed: 150 mm²/min
Max Machining Current: 6 A
Wire Electrode Diameter: φ0.15~ φ0.20mm
Coolant Tank Capacity: 100 L
Power Supply: 3N~ 380 V / 50 Hz, or customized
Power Consumption: 3 kVA
Models (D)
Cutting Thickness: 500 mm
Max Taper (no more than 100mm): 6°
Product Parameters
| Model |
DK7732 |
DK7740 |
DK7750 |
DK7763 |
| X,Y travel: |
320×400 mm |
400×500 mm |
500×630 mm |
630×800 mm |
| Worktable size: |
415×635 mm |
500×785 mm |
600×900 mm |
660×1100 mm |
| Max loading weight: |
400 kg |
500 kg |
800 kg |
3000 kg |
| Machine weight: |
1500 kg |
1700 kg |
2300 kg |
4500 kg |
| Precision: |
≤ ±0.0075 mm |
≤ ±0.0075 mm |
≤ ±0.0075 mm |
≤ ±0.0075 mm |
Roughness: One-time cutting ≤ 2.5 μm Multi-cutting ≤ 1.5 μm
The parameters above are all based on the BMW-3000 controller. There are also higher-configuration options available (BMW-7000, BMW-8000). In terms of performance, cutting efficiency increases by 40%, achievable accuracy is within ±5 μm, and surface roughness is 0.8 μm (using multiple cutting passes).
